Key features：

■ It adopts the latest ADI five series chips and 64-bit high-speed dual-core DSP processors.

■ The music channel has a 9-band PEQ stereo equalizer and automatically recognizes the optical audio digital input.

■ The microphone has 15 segments of PEQ individually adjusted, full digital audio processing system, stereo DSP multiple digital reverberation, and the vocal effect is more professional.

■ Microphone silencing setting, independent pressure limit design; Frequency shift 2Hz~8Hz optional feedback suppression, and optional "OFF".

■ The effect channel is equipped with independent high-pass and low-pass, and the reverb and echo are respectively equipped with 5-band parametric equalization (PEQ) and other functions.

■ Each output channel is equipped with 7 parametric equalization (PEQ), high and low pass adjustment, mixing ratio, polarity, time delay, voltage limit, and gain functions.

■ Support VOD infrared interface to control the machine.

■ Support RS232 connection computer control machine, equipped with professional PC equipment management and control software.

■ The built-in RTA spectrum display can more effectively find the acoustic frequency point, so that the acoustic noise is traceless.

■ Three-level engineering password lock function, you can set the device lock level according to the needs of use.

■ It can store 9 groups of system modes, and the boot state is the last time the machine saves data.

Product Parameters：

Music Port Max Input Level: +14dBu (4V RMS)

Output Channel Max Output Level: +14dBu (4V RMS)

Music Gain: 0dB, +3dB, +6dB (3 steps selectable)

Microphone Sensitivity: 64mV (Out: 4V)

Signal-to-noise ratio: >90dB

Power supply: 220V/AC/50Hz

Size: 483*218.5*47.5mm

Net weight: 3.5KG
