Key features：

■ The S-212 is a three-way design consisting of 2 x 12" LF drivers, a horned 10" MF driver, and two 1.4" throat, 3" voice coil HF compression drivers with dedicated waveguides. The mechanical and acoustic design allows up to 24 loudspeakers to be combined to be hung in a vertical line array, and the vertical opening angle can be adjusted between 0°~7° with an adjustment accuracy of 1°, and the cylindrical wave produces a consistent coupling in the vertical plane. Due to the dipole symmetry of the neodymium low-frequency drivers, the lower limit of constant directivity control at 80° can be extended to 250Hz.

■ The S-212 loudspeaker cabinet is made of marine plywood and features a crash- and weather-resistant PCP (Polyurea Cabinet Protection) coating. The front of the cabinet is protected by a rigid metal grille, and the side and rear panels are equipped with four handles, and the rear panel is equipped with two NLT4F connectors in parallel.

Product Parameters：

System type: dual 12 three-way line array speakers

Frequency response (-5 dB standard): 50 Hz - 17 kHz

Frequency response (-5 dB CUT mode): 87 Hz - 17 kHz

Maximum sound pressure: 143dB

Part parameters

Nominal impedance LF/MHF: 6/12Ω

Power Handling Capability LF (RMS/Peak 10ms): 500/2000w

Power Handling Capability MHF (RMS/Peak 10ms) 200/800w

Nominal dispersion angle (horizontal): 80°

The splay angle is set to 0... 7 (increment 1°) °

Woofer: 2×12" LF driver (neodymium)

Midrange: 1×10" MF driver (neodymium)

Tweeter: 2×1.4" HF compression driver (neodymium)

Dimensions (height× width × depth): 360mm× 1100mm× 570mm

Gross weight: 65.6Kg
