Key features：

■ The L-15F is designed for mid-range projection applications, with a built-in crossover 15-inch speaker with extremely flexible layout and ease of use.

■ Combined with a controlled 10° dispersion angle, the L15F has an impressive 140dB output and its throw distance can reach up to 45 meters. Allows the user to adjust the directivity to cover a specific geometry of the audience area and ensure excellent stability of the frequency response.

■ L15F and L15W can be hung together or stacked to form a vertical line array. A single L15F can also be used as a point source with adjustable directivity for applications such as front fills or delay fills that require narrow coverage.

■ The L15F provides a large concert-level low-frequency response, while the L-218 subwoofer further enhances the low-frequency response and extends the lower frequency response to 30Hz.

Product Parameters：

Frequency response range: 45Hz-20KHz

Nominal impedance: 8Ω

Unit Composition:

LF: 1 × 15'' neodymium conical driver

HF: 1 × 3'' diaphragm neodymium compression driver

Projection angle: 30°×70/90°/110°, can be adjusted at will

Maximum sound pressure: 140dB

Box material: birch multi-layer plywood

Spray color: brown polyurea paint

Protective surface: black perforated steel + sound-permeable cloth

Input/output: Four-core speaker plug

Dimensions: 430mm× 750mm× 495mm

Gross weight: 35.3kg
